Lightweight notcher MZ 02 90F A L
2.650,00 € without VAT.
The MZ 02 90F A L light notcher has been designed for the light processing of CLT cross laminated timber.
Roundings on inside corners are milled outthat remain after milling a cut-out.
- Removing the rounding of an inside corner except for a bottom or fold in the Workpiece
- Immersion in cut-outs from approx. 250 mm x 250 mm, with fixed cable also approx. 200 mm x 200 mm, immersion from approx. 400 mm x 400 mm,
- Up to 290 mm depth as standard
- Easy to work with due to greatly reduced weight, from over 13 kg for the Large notchers to just under 4 kg now!
The customer of the cross laminated timber receives a higher quality workpiece.
Description
The rounding in an inside corner can be removed down to a floor.
When milling a cut-out in cross laminated timber, the cut-out part remains in the workpiece. The workpiece must be removed from the machine to remove it. Subsequent repositioning is therefore necessary. This is laborious and time-consuming.
The MZ 02 90F A L lightweight notcher eliminates the need for repositioning with milling accuracy. While the roundings in the inside corners of the first workpiece are being removed, a second workpiece can already be processed on the milling machine.
The processing is taken off the customer's hands, which is becoming increasingly popular as a general trend.
Due to its innovation, the L notcher was promoted at the Holz-Handwerk 2022 trade fair in Nuremberg:
Further information
Lightweight notcher MZ 02 90F A L
for CLT cross laminated timber for milling internal corners
We would like to offer you a new manual machine for Processing of cross laminated timber introduce.
The new manual machine can be used to Rounded inside corners of cut-outs that remain after milling, remove. The machine is called notcher L for short.
Compared to the previous model, the notcher L has the following changes:
Weight greatly reducedfrom over 13 kg to just under 4 kg!
Removing the rounding of a Inside corner down to one floor or fold in the workpiece
Immersion in cut-outs from approx. 250 mm x 250 mm, with fixed cable also approx. 200 mm x 200 mm, immersion from approx. 400 mm x 400 mm
- Maximum thickness of the workpiece: approx. 290 mm as standard
The machine is much easier to handle and is also the first manual machine known to us that can mill internal corners flush with the floor.
In addition, due to the modified design with fewer components and the use of plastic 3D printed parts the price is also significantly reduced could be realised.
In the standard version, curves up to R = 20 mm can be milled. On request, R = 25 mm is also possible with a design modification. Depending on the cutter tap used, a remnant remains in the inside corner, forming a plane about 1.5 mm wide.
We offer you a mobile, hand-guided machine for removing the inside corner roundings on glulam. The material is spruce and/or pine.
